High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head

High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head

Model NO.
YZm
High-Intensity Adjustable Pressure Customizable High-Quality Peristaltic Pump Head
Quantity:

YZm easy-to-install series Peristaltic Pump Heads provide two options of single and double channels, and can also be used in series with multiple Peristaltic Pump Heads according to customer needs. YZ25m adjustable peristaltic pump head has a maximum treatment liquid volume of 3L/min, which can transfer more viscous liquids.


Technical Parameters:

Model
    YZ15m/YZ15ma/YZ15mt/YZ15mat
YZ25m/YZ25ma
Speed
0.1-600rpm
Flow rate
0.007-2280ml/min
0.17-3000ml/min
Channel
Single/dual channel optional
Single
Roller material
Stainless steel
Number of rollers
3
Tube
13# 14# 19# 16# 25# 17# 18#
15# 24# 35# 36#

Model
Tube
ID* wall thickness(mm)
Flow rate(ml/min)
Speed (rpm)
      YZ15m
13#
0.8*1.6
0.007—42
Max 600
14#
1.6*1.6
0.027—162
Max 600
19#
2.4*1.6
0.051—306
Max 600
16#
3.1*1.6
0.082—492
Max 600
25#
4.8*1.6
0.17—1020
Max 600
17#
6.4*1.6
0.29—1740
Max 600
18#
7.9*1.6
0.38—2280
Max 600
      YZ15m
(Dual channel)
13#
0.8*1.6
0.007—42
Max 600
14#
1.6*1.6
0.027—162
Max 600
19#
2.4*1.6
0.051—306
Max 600
16#
3.1*1.6
0.082—492
Max 600
25#
4.8*1.6
0.17—1020
Max 600
     YZ25m
15#
4.8*2.4
0.17—1020
Max 600
24#
6.4*2.4
0.29—1740
Max 600
35#
7.9*2.4
0.38—2280
Max 600
36#
9.6*2.4
0.5—3000
Max 600
