Model NO.
BT600M/YZ1515x
* Drive Model: BT600M
* Speed range : 0.1-600 rpm（reversible）
* Flow range : 0.007~2280ml/min
* Max channels :2
* Remote control : optional
* Pump Head :YZ1515x,YZ2515x, ZN series, KZ25
Quantity:

Parameter


ModelBT600MDisplay Mode4-LED
Speed Range0.1-600 rpmControl MethodRotary encoded knob
speed resolution0.1 rpmMotor TypeStepper motor
Flow range0.007-2280 ml/minExternal control
Start & stop, direction control, speed control
( Analog control :0-5v, 0-10v, 4-20mA optionl )
RS232 and RS485 Communication interface, support MODUBUS Communication Protocol
Environment Temperature0-40℃
Relatively Humidity<80%
Power consumption<50w
Power supplyAC220V or  AC110V

Tube For pump head MODEL; YZ1515x
Tube
ID(mm)
Wall thickness(mm)
OD(mm)
Flow rate ml/min
13#
0.8
1.6
4
0.007-42
14#
1.6
1.6
4.8
0.027-162
19#
2.4
1.6
5.6
0.051-306
16#
3.1
1.6
6.3
0.082-492
25#
4.8
1.6
8
0.17-1020
17#
6.4
1.6
9.6
0.29-1740
18#
7.9
1.6
11.1
0.38-2280
Tube for peristaltic pump head   YZ2515x
Tube
ID(mm)
Wall thickness(mm)
OD(mm)
Flow rate(ml/min)
15#
4.8
2.4
9.6
0.17—1020
24#
6.4
2.4
11.2
0.29-1740
