ACM Small Speed Chemical Transfer Peristaltic Dosing Pump

Model NO.: ACM205

* Motor: Motor:AC110V synchronous motor /AC220V synchronous motor
* Pump head：TH15
* Max speed : 100 rpm
* Flow range : 0~170ml/min

Quantity:

Product Description

This pump can work with AC220V synchronous motor
1.The TH15 pumps have superb features built-in and flexible design to meet specific customer needs.
2.Flexible rotor assembly, occlusion can be adjusted automatically, which give this OEM peristaltic pump a good performance.

Application:
Environmental Protection Equipment,Discharge of flue gas analyzer,Delivery liquid into the fermentation tank

Model	Pump head	Motor Voltage	Motor speed	Tube mode &Flowrate (ml/min)	Order Number
ACM205	TH15	AC220V	100 rpm	17# 290ml/min 25# 170ml/min 16# 82ml/min	205100-17 205100-25 205100-16
ACM205	TH15	AC220V	60rpm	17# 174ml/min 25# 102ml/min 16# 49ml/min	20560-17 20560-25 20560-16
ACM205	TH15	AC220V	30rpm	17# 87ml/min 25# 51ml/min 16# 24ml/min	20530-17 20530-25 20530-16
ACM205	TH15	AC220V	10rpm	17# 29ml/min 25# 17ml/min 16# 8ml/min	20510-17 20510-25 20510-16

Functions and features

*A special part links the roller box with the motor shaft to ensures stable
*Snaps into the tube, not slippery silk, more fixture
*Crust use streamlined design, With card bit, easily snaps into the pump
. Easy to change and fix the tubing. Occlusion can be adjusted slightly by ratchet wheel.
* Small size, compact and robust design
* Trouble-free continuous tube loading in seconds
* Reliable performance without any operator adjustments
* Safe and closed with visible rotor movement
* Spring-loaded operation for good pressure control
* 2 roller pump head, low pulsation
* Smooth, cog-free operation

Noted:Run clockwise can get large flow,and operation counterclockwise can get biger outlet pressure.
Load import tube or harder tube,please counterclockwise operation to increase the pressure tube torque.
